What is DD14 forming steel?
DD14 pushes the hot-rolled forming family to its limit: the same 0.08 % carbon ceiling as DD13 but manganese reduced to 0.35 %, phosphorus and sulphur to 0.025 %, a tighter and lower yield window (170–290 MPa), a lower tensile ceiling (380 MPa) and 36 % elongation, all with the non-ageing guarantee. The mill achieves it with a very clean aluminium-killed heat and a controlled coiling temperature that produces a coarse, soft, uniform ferrite — the hot-rolled equivalent of the annealing texture that makes DC05 draw. In the press it gives draw ratios above 2, two-stage draws without intermediate annealing, and stretch-forming of large hot-rolled panels. Typical parts: deep LPG/CNG cylinder halves and re-drawn necks, wheel discs with integral hubs, deep hot-rolled housings and cups, pressed axle and suspension components. It is always pickled and oiled; it is not a stock grade anywhere in Turkey and is rolled against order in 3–4 weeks.
Chemical composition
| Element | C | Mn | P | S |
|---|---|---|---|---|
| max. % (ladle) | 0.08 | 0.35 | 0.025 | 0.025 |
Typical heat: C 0.02–0.03, Mn 0.15–0.25, Al 0.03–0.06.
Mechanical properties and deep-drawing behaviour
| Property | Requirement | Typical value | Note |
|---|---|---|---|
| Yield strength ReH | 170–290 MPa (≤ 310 below 2 mm) | 180–240 MPa | |
| Tensile strength Rm | ≤ 380 MPa | 290–340 MPa | |
| Elongation A80 | ≥ 36 % | 38–44 % | |
| r / n (typical) | not specified | ≈ 1.4 / 0.21 | |
| Bend radius | 0 × t | passes | |
| Ageing | non-ageing 6 months | guaranteed |
Equivalent grades
| System | Grade | Note |
|---|---|---|
| DIN 1614-1 (old) | StW 24 (special) | historic German |
| EN 10111 (1998) | DD14 | previous edition |
| JIS G3131 | SPHF | |
| ASTM A1011 | EDDS (hot-rolled) | |
| GB/T 3273 / 5213 | SPHF |
Surface and oiling on the deepest-drawing hot-rolled grade
| Condition | Process | Surface | Best for |
|---|---|---|---|
| Black (HR, as-rolled) | none — mill scale left on | blue-black oxide, 10–40 µm, flakes when bent | welded structures, plate to be blasted, hidden parts |
| HRPO (pickled & oiled) | HCl pickling of coil, rinse, light oil | uniform grey-metallic, scale-free, Ra ≈ 1–3 µm | forming, painting, roll-forming, tube making, visible parts |
| HRP / HRPO skin-passed | pickling + temper pass | flatter, tighter gauge, no Lüders lines | pressing, blanking, precision parts |
| Dry (pickled, unoiled) | pickling, no oil | bare, rusts within days | immediate galvanizing or welding only |
DD14 is bought pickled, oiled and skin-passed; there is no sensible reason to draw a 30 %-elongation grade through mill scale. Dry (unoiled) delivery only makes sense when the part goes straight to galvanizing.
Thickness range and stock sizes
| Thickness | Widths × lengths | Availability |
|---|---|---|
| 1.5–3.0 mm | coil 1 000 / 1 250 / 1 500 mm; blanks | to order 3–4 weeks |
| 4.0–6.0 mm | coil 1 250 / 1 500 mm; blanks | to order 3–4 weeks |
Weight per m² and per sheet
| Thickness | kg/m² | 1 000 × 2 000 (kg) | 1 250 × 2 500 (kg) | 1 500 × 3 000 (kg) |
|---|---|---|---|---|
| 1.5 mm | 11.78 | 23.6 | 36.8 | 53.0 |
| 2 mm | 15.70 | 31.4 | 49.1 | 70.7 |
| 2.5 mm | 19.63 | 39.3 | 61.3 | 88.3 |
| 3 mm | 23.55 | 47.1 | 73.6 | 106.0 |
| 4 mm | 31.40 | 62.8 | 98.1 | 141.3 |
| 5 mm | 39.25 | 78.5 | 122.7 | 176.6 |
| 6 mm | 47.10 | 94.2 | 147.2 | 212.0 |
Uncoated; tolerances to EN 10051.
Forming, welding and painting
Draw ratios above 2, redraws without annealing, stretch-forming of large parts; low blank-holder force, generous radii, drawing oil, polished tools. Welds without preheat with soft, ductile joints; cylinder procedures to EN 10120 / EN 1442 on request. Paint after degreasing.
Where it is used
- Deep LPG / CNG cylinder halves and re-drawn necks
- Wheel discs with integral hubs
- Deep hot-rolled housings, cups and covers
- Pressed axle, suspension and steering components
- Two-stage drawn agricultural and machinery parts
DD14 vs DD13
DD13 from stock draws to a ratio of about 1.9; DD14 to above 2 with a redraw, at about 15 USD/t more and a mill lead time. Try the part in DD13 first unless the specification names DD14 or the draw ratio is known to exceed 2. For thin parts the cold-rolled DC05 is the equivalent level.
Price
Budget about 35 USD/t above pickled DD11. DD14 is an aluminium-killed mill order with a guaranteed elongation floor, so the premium buys the slot and the sorting rather than extra alloy. Indicative FOB Istanbul range below.
Bands from our weekly export list (September 2026), FOB Istanbul, full-container quantities, excluding freight and certificates. Firm price per project on RFQ within one working day.
Export and packing
Packing for DD14 forming steel: coil eye-to-sky, VCI paper; blanks interleaved on skids. Loading: 20' one coil ≤ 20 t; 40' HC two coils. Customs classification is by surface and alloy content — 7208, 7209, 7210, 7225 or 7226.
| Term | Detail |
|---|---|
| MOQ | One coil (10–25 t) |
| Incoterms | FOB Istanbul · CIF / CFR Gulf, Africa · DAP EU, Balkans, Iraq, Caucasus · DAP Aktau |
| Lead time | To order 3–4 weeks |
| Packing | Coil eye-to-sky, VCI paper; blanks interleaved on skids |
| Container / truck | 20' one coil ≤ 20 t; 40' HC two coils |
| Documents | Invoice, packing list, EN 10204 3.1 (3.2 on request), certificate of origin; SASO / SONCAP / PVoC on request |
| Payment | 30% advance, balance against B/L copy; L/C at sight for orders above 100 t |
Certificates and testing
Each coil of DD14 forming steel carries an EN 10204 3.1 certificate: heat, chemistry, yield, tensile and elongation. If a 3.2 certificate is required, say so at enquiry — it fixes which mill we can use. Retained samples are held for six months so that a later claim can be checked against the same coil.
How to order
Specify thickness × width or blank size, tonnage, the part drawing and any cylinder certification; mill slot confirmed within one working day.
Standards
- EN 10111:2008 — DD14, 1.0389
- EN 10051 — tolerances
- EN 10204 3.1
- Former EN 10111 (1998) DD14
Grades
Grade data sheets (chemistry, mechanicals, equivalents) are on our reference site: DD14 · DD13 · DC05
Frequently asked questions
What is DD14 steel?
The extra-deep-drawing hot-rolled steel of EN 10111 (1.0389): very clean Al-killed heat, yield 170–290 MPa, elongation ≥ 36 %, non-ageing, pickled and oiled, for the deepest hot-rolled pressings in 1.5–6 mm.
What is the difference between DD13 and DD14?
DD14 has lower manganese, phosphorus and sulphur, a narrower yield window (170–290 vs 170–310 MPa) and 36 % vs 33 % elongation, allowing draw ratios above 2; DD13 is the stock deep-drawing grade.
What is the equivalent of DD14?
JIS SPHF; ASTM A1011 EDDS (hot-rolled); no exact DIN predecessor.
What is the lead time for DD14?
3–4 weeks — rolled to order; DD13 ships from stock.
