What is RAL 9005 PPGI sheet?
RAL 9005, Tiefschwarz, is a neutral deep black made on carbon-black pigment — the most light-fast pigment there is, so the colour itself does not fade; what ages a black roof is the binder, which chalks to a grey bloom under UV and heat, and the heat itself: a 9005 surface absorbs about 95 % of solar radiation and reaches 80–90 °C on a Gulf or Anatolian summer afternoon. That is why black is specified as matt-textured polyester (the wrinkle texture scatters light so the surface reads black even when slightly chalked, and hides oil-canning on wide flat panels) or as PVDF, whose fluoropolymer binder does not chalk, and why standing-seam and cassette systems in black are detailed with expansion allowance and insulation beneath. On the building it is the colour of contemporary villas, showrooms, restaurants, pergolas, sliding gates and fence panels, black-framed windows and doors, and of the increasingly popular black metal roof on Scandinavian-style houses in the Balkans and Turkey. We stock 9005 in matt-textured PE 0.50 mm and gloss PE 0.40–0.50 mm on 1 250 mm coil, roll it into standing-seam (25 / 38 mm), trapezoidal 27/150 and 38/151 and façade cassette blanks on our lines, and fold flashings, copings and fence rails from the same batch; PVDF and SMP 9005 are ordered per project from 10 t.
Colour data
| RAL code | Name | Approx. hex | Light reflectance (LRV) | Gloss (60°) | Colour tolerance |
|---|---|---|---|---|---|
| RAL 9005 | Jet black / Tiefschwarz | #0E0E10 | ≈ 4 % | 30–40 gloss; 5–10 matt textured | ΔE ≤ 1.0 to RAL 841-GL, batch-matched |
Which paint system holds this colour
| System | Chalking | ΔE at 10 yr | Gloss kept | Typical use |
|---|---|---|---|---|
| PE polyester gloss 25 µm | moderate — grey bloom | 2–4 | 30–50 % | fences, gates, indoor, short-life cladding |
| Matt-textured PE 30 µm | masked by texture | 1.5–2.5 | n/a | standing-seam roofs, cassettes, villas — the stock architectural black |
| SMP / HDP 25 µm | low | 1–2 | 60–75 % | roofs with 15–20-yr warranty |
| PVDF 25–35 µm | very low | ≤ 1 | > 80 % | façades, showrooms, colour warranty 20–25 yr |
Carbon black does not fade; the binder chalks. Surface temperature 80–90 °C in summer: never fix black panels rigidly over long runs, and use PVDF or matt-textured PE wherever the surface is seen from close by.
Heat and expansion on a black roof
| Colour | Solar absorptance | Surface temp. | Movement per 10 m panel (Δ 60 °C) | Design note |
|---|---|---|---|---|
| RAL 9016 white | ≈ 25 % | 45–50 °C | ≈ 7 mm | fixed fastening acceptable |
| RAL 9002 grey white | ≈ 30 % | 50–55 °C | ≈ 7 mm | roofing standard |
| RAL 7016 anthracite | ≈ 85 % | 75–80 °C | ≈ 11 mm | sliding clips on runs > 8 m |
| RAL 9005 black | ≈ 95 % | 80–90 °C | ≈ 12 mm | standing seam with sliding clips; insulation beneath; matt or PVDF |
Steel expands 12 µm per metre per °C. A black standing-seam roof over 10 m must slide on its clips; a black trapezoidal sheet screwed through the crest at 10 m length will elongate its holes. Sandwich panels in 9005 are limited to 6–8 m by most panel makers for the same reason.
Thickness range and stock sizes
| Thickness | Widths × lengths | Availability |
|---|---|---|
| 0.50 mm matt textured | 1 250 mm coil; sheet / panel to 13.5 m | stock — standing seam, cassettes |
| 0.40–0.50 mm gloss | 1 000 / 1 250 mm coil | stock — fences, gates, cladding |
| 0.60–0.70 mm | 1 250 mm coil | to order — cassettes, doors, copings |
| SMP / PVDF | 0.50–0.70 mm | to order, 10 t per system |
Weight per m² and per sheet
| Thickness | kg/m² | 1 000 × 2 000 (kg) | 1 250 × 2 500 (kg) | 1 500 × 3 000 (kg) |
|---|---|---|---|---|
| 0.35 mm | 2.85 | 5.7 | 8.9 | 12.8 |
| 0.4 mm | 3.24 | 6.5 | 10.1 | 14.6 |
| 0.45 mm | 3.63 | 7.3 | 11.4 | 16.3 |
| 0.5 mm | 4.03 | 8.1 | 12.6 | 18.1 |
| 0.6 mm | 4.81 | 9.6 | 15.0 | 21.6 |
| 0.7 mm | 5.60 | 11.2 | 17.5 | 25.2 |
Weights use 7.85 kg/dm³ steel, Z100 zinc and the 25/7 µm black system (≈ 0.10 kg/m²); the thickness column is TCT.
Forming, cutting and handling
Roll-forms into standing-seam and trapezoidal profiles and folds to 1–2 × t (matt-textured to 3T) with the film on; shears, slits and punches cleanly; laser and plasma are avoided. Every scratch on black shows as silver zinc — film stays on until the panel is clipped, panels are lifted with slings not chains, and edges and fixings are touched up with 9005 repair paint. Do not stack black packs in the sun with film on: the film adhesive can bake onto matt paint above 60 °C.
Where it is used
- Standing-seam roofs and wall panels on contemporary houses and showrooms
- Façade cassettes, copings and soffits
- Fence panels, sliding gates, pergolas and carports
- Doors, shutters, window trims and garage doors
- Restaurant, retail and office fit-out cladding
- Black roof and wall sandwich panels (short lengths)
RAL 9005 vs 7016 vs 7021
RAL 7016 anthracite is the practical dark colour — 10 °C cooler, less chalk-sensitive and the default for dark trapezoidal roofs and panels; 9005 is chosen only when true black is the design intent. RAL 7021 black grey sits between them and is a to-order colour. Warm dark alternatives are RAL 8017 brown; all colours on the PPGI hub.
Price
RAL 9005 carries about 25 USD/t over the 9002 base (carbon black is cheap, but the matt-textured and the tighter batch control are not); PVDF adds 30–40 %, SMP 15–20 %. Bands below are the month's indicative FOB Istanbul ranges for 0.50 mm PE and the stock gauge range; standing-seam panels are quoted per m² on the roofing page.
Bands from our weekly export list (September 2026), FOB Istanbul, full-container quantities, excluding freight and certificates. Firm price per project on RFQ within one working day.
Export and packing
Packing of RAL 9005 PPGI sheet: coils on cradles (eye-to-sky, VCI wrap, four straps, 5–25 t) or sheet packs on skids up to 3 t with interleaving paper and corner protectors; 20' ≈ one coil (≤ 20 t), 40' HC ≈ two coils or 24 t of sheet. Tariff 7210 / 7209 / 7208.
| Term | Detail |
|---|---|
| MOQ | 3 t stock black; 10 t for gloss or PVDF |
| Incoterms | FOB Istanbul · CIF / CFR Gulf, Africa · DAP EU, Balkans, Iraq, Caucasus · DAP Aktau |
| Lead time | Matt-textured black 0.50–0.70 mm from stock in 3–7 working days; gloss black and PVDF 3–5 weeks |
| Packing | Coils 3–8 t on cradles with PE film and VCI paper; standing-seam and cassette sheet on skids with a protective film on the face, since black shows handling marks first |
| Container / truck | A 20' holds two 9 t coils; a 40' HC about 24 t of sheet |
| Documents | Invoice, packing list, EN 10204 3.1 (3.2 on request), certificate of origin; SASO / SONCAP / PVoC on request |
| Payment | 30% advance, balance against B/L copy; L/C at sight for orders above 100 t |
Certificates and testing
Documentation for RAL 9005 PPGI sheet: EN 10204 3.1 mill certificate as standard (heat number, analysis, tensile, Charpy, condition); 3.2 with an independent inspector, EN 10160 UT reports and additional low-temperature Charpy tests are available on plates above 8 mm at order.
How to order
Specify RAL 9005, matt textured or gloss, thickness (TCT), width, coil or panel lengths, coating system (matt PE stock / SMP / PVDF), zinc class (Z140–Z275 recommended for black), backing coat, film and quantity; say whether the surface is roof, façade or fence so the right system is quoted.
Standards
- EN 10169 — continuously organic-coated (coil-coated) steel
- EN 10346 — DX51D+Z substrate
- RAL 841-GL colour register
- EN 13523 (ECCA) test methods; EN 10204 3.1
Grades
Grade data sheets (chemistry, mechanicals, equivalents) are on our reference site: DX51D · S250GD · DX52D
Frequently asked questions
What colour is RAL 9005?
Jet black — the darkest coil-coated colour (LRV ≈ 4 %), the architectural black of standing-seam roofs, façade cassettes, fences and doors.
Does black PPGI fade?
The carbon-black pigment does not fade; plain gloss polyester chalks to a grey bloom in 5–10 years of sun. Matt-textured PE or PVDF keeps it black.
How hot does a black metal roof get?
80–90 °C surface temperature on a summer afternoon — plan insulation underneath and sliding clips on standing-seam runs over 8–10 m.
RAL 9005 or RAL 7016 for a dark roof?
7016 anthracite is cooler, more forgiving and the usual dark roof; 9005 only when true black is the design intent, and then in matt-textured or PVDF.
Is RAL 9005 available in matt?
Yes — matt-textured PE 0.50 mm from stock; it is the finish most architects specify for black roofs and façades.
What is the price of RAL 9005 PPGI?
About 25 USD/t over RAL 9002 in PE; see the indicative FOB Istanbul bands above. PVDF is quoted per project from 10 t.
