What is RAL 6009 PPGI sheet?
RAL 6009, Tannengrün, is a very dark blue-green with a light-reflectance value around 5 % — in shade it reads as black, in sunlight as deep pine green. Coil coaters build it on chromium-oxide green with a phthalocyanine blue shade and a little carbon black, all inorganic or highly stable pigments, so unlike bright greens it does not shift hue as it ages; what happens to a 6009 roof after ten years of sun is a slight greying of the polyester binder (chalking), which matt-textured PE hides and SMP or PVDF prevents. Its absorptance of about 90 % puts surface temperatures at 75–85 °C in a Gulf or Anatolian summer, so long panels are fixed with expansion allowance and roofs are insulated beneath. On the market it is the colour that planning authorities ask for in forests, national parks and coastal reserves, the standard green of steel fences and gates in Europe, of pergolas and carports, of military, border-post and hunting-lodge buildings, of agricultural sheds in wooded regions and of sandwich-panel walls that must blend with a tree line. We stock 6009 in 0.40 and 0.50 mm PE on 1 000 and 1 250 mm coil, roll it into fence panels, trapezoidal 27/150 and 38/151 and corrugated 18/76 on our lines, fold post caps, rails and flashings from the same batch, and order matt-textured, SMP and PVDF 6009 per project from 10 t.
Colour data
| RAL code | Name | Approx. hex | Light reflectance (LRV) | Gloss (60°) | Colour tolerance |
|---|---|---|---|---|---|
| RAL 6009 | Fir green / Tannengrün | #27352A | ≈ 5 % | 30–40 gloss; 5–15 matt textured on request | ΔE ≤ 1.0 to RAL 841-GL, batch-matched |
Colour retention by paint system
| System | Pigments | Chalking | ΔE at 10 yr | Typical use |
|---|---|---|---|---|
| PE polyester 25 µm | chromium oxide + phthalocyanine | slight–moderate (dark, runs hot) | 2–3 | fences, gates, sheds, temperate roofs |
| Matt-textured PE 30 µm | same | masked by texture | 1.5–2.5 | forest and park roofs, visible fences |
| SMP / HDP 25 µm | same | low | 1–2 | Gulf and high-UV roofs, 15-yr warranty |
| PVDF 25–35 µm | same | very low | ≤ 1 | architectural cladding, colour warranty |
The pigments of 6009 are stable — the hue does not drift to blue or yellow the way organic greens do; the risk is chalking of the binder on a hot dark surface. Matt-textured or SMP for anything seen from close by in strong sun.
Fence, gate and screening products in RAL 6009
| Item | Gauge | Note |
|---|---|---|
| Fence panel sheet (trapezoidal 18/76 or 20/125) | 0.40–0.50 mm | 1.5–2.5 m heights, cut to length |
| Gate and door skins | 0.50–0.70 mm | flat or micro-ribbed, film both sides |
| Post caps, top rails and U-channels | 0.50–0.70 mm | folded from the same coil |
| Trapezoidal 27/150 and 38/151 roof and wall sheet | 0.40–0.50 mm | forest and agricultural roofs |
| Corrugated 18/76 | 0.40–0.50 mm | sheds, screening walls |
| Sandwich-panel outer skins | 0.50–0.60 mm | PIR / rockwool walls that blend with trees |
| Screws with painted heads | — | 6009 heads, EPDM washers |
Fence sheet, posts caps, rails and screws from one batch: dark greens from different paint runs can differ by 1–2 ΔE, visible along a fence line.
Thickness range and stock sizes
| Thickness | Widths × lengths | Availability |
|---|---|---|
| 0.40–0.50 mm | 1 000 / 1 250 mm coil; sheet to 6 000 mm | stock — fences, roofs, sheds |
| 0.60–0.70 mm | 1 250 mm coil | to order — gates, doors, copings |
| 0.35 mm | 1 000 mm coil | to order — light screening |
| Matt / SMP / PVDF | 0.45–0.60 mm | to order, 10 t per system |
Weight per m² and per sheet
| Thickness | kg/m² | 1 000 × 2 000 (kg) | 1 250 × 2 500 (kg) | 1 500 × 3 000 (kg) |
|---|---|---|---|---|
| 0.35 mm | 2.85 | 5.7 | 8.9 | 12.8 |
| 0.4 mm | 3.24 | 6.5 | 10.1 | 14.6 |
| 0.45 mm | 3.63 | 7.3 | 11.4 | 16.3 |
| 0.5 mm | 4.03 | 8.1 | 12.6 | 18.1 |
| 0.6 mm | 4.81 | 9.6 | 15.0 | 21.6 |
| 0.7 mm | 5.60 | 11.2 | 17.5 | 25.2 |
Weights are for 7.85 kg/dm³ steel with Z100 zinc and the dark-green 25/7 µm system (≈ 0.10 kg/m²); the thickness column is TCT.
Forming, cutting and handling
Roll-forms into fence, trapezoidal and corrugated profiles and folds at 1–2 × t with the film on; shears, slits and punches cleanly — plasma and laser burn the paint. Scratches on 6009 show as bright zinc against near-black, so the film stays on until the panel is fixed, cut edges are deburred and touched up with 6009 repair paint (supplied), and packs are stored under cover. Fence panels cut on our shear are supplied with film and deburred edges; do not weld pre-painted 6009 — rivet or screw.
Where it is used
- Steel fences, gates, screening walls and post caps
- Roofs and walls in forests, parks, coastal reserves and planning-restricted sites
- Pergolas, carports, garden buildings and kiosks
- Military, border-post, hunting and forestry buildings
- Agricultural sheds and stables in wooded regions
- Sandwich-panel walls that must blend with a tree line
RAL 6009 vs 6005 vs 6020
RAL 6005 moss green is warmer and lighter (LRV ≈ 8 %) — the agricultural and landscape green of the Balkans and Anatolia and our stock green for roofs; 6009 is darker and bluer, the fence and forest green that disappears among trees. RAL 6020 chrome green is close to 6009 but yellower and is a to-order colour. For a black alternative on fences and pergolas see RAL 9005; all colours and systems on the PPGI hub.
Price
RAL 6009 carries about 30 USD/t over the RAL 9002 base (chromium-oxide and phthalocyanine pigment loading); matt-textured adds 5–8 %, SMP 15–20 %, PVDF 30–40 %. Bands below are the month's indicative FOB Istanbul ranges for 0.50 mm PE and the stock gauge range; fence panels and trapezoidal sheet are quoted per m² on the profile pages.
Bands from our weekly export list (September 2026), FOB Istanbul, full-container quantities, excluding freight and certificates. Firm price per project on RFQ within one working day.
Export and packing
We load RAL 6009 PPGI sheet as slit or master coils on cradles (VCI paper, strapped, 5–25 t) or as cut-to-length sheet on skids (≤ 3 t, interleaved, edge boards); a 20' container carries one coil to 20 t, a 40' HC two coils or 24 t of sheet. HS 7210 / 7209 / 7208.
| Term | Detail |
|---|---|
| MOQ | 3 t from stock; 10 t for matt, SMP or PVDF |
| Incoterms | FOB Istanbul · CIF / CFR Gulf, Africa · DAP EU, Balkans, Iraq, Caucasus · DAP Aktau |
| Lead time | Fir green 0.40–0.50 mm PE from stock in 3–7 working days; matt-textured, SMP and PVDF 4–6 weeks |
| Packing | Coils 3–8 t on cradles, eye-to-sky, PE film and VCI paper; fence and roof panels on skids with film, strapped with corner boards |
| Container / truck | A 20' takes two coils (≈ 18 t); a 40' HC about 24 t of sheet or profiled panels |
| Documents | Invoice, packing list, EN 10204 3.1 (3.2 on request), certificate of origin; SASO / SONCAP / PVoC on request |
| Payment | 30% advance, balance against B/L copy; L/C at sight for orders above 100 t |
Certificates and testing
RAL 6009 PPGI sheet is delivered with the mill certificate EN 10204 3.1 — heat number, ladle analysis, tensile and impact results and the delivery condition. Third-party 3.2 certification (Lloyd's, BV, TÜV, SGS), ultrasonic testing to EN 10160 and extra Charpy tests at a lower temperature are ordered per lot.
How to order
Specify RAL 6009, gloss or matt textured, thickness (TCT), width, coil or sheet / panel length (or fence height and run), coating system (PE stock / SMP / PVDF), zinc class, backing coat, film and quantity; order panels, caps, rails and screws together for one batch.
Standards
- EN 10169 — continuously organic-coated (coil-coated) steel
- EN 10346 — DX51D+Z substrate
- RAL 841-GL colour register
- EN 13523 (ECCA) test methods; EN 10204 3.1
Grades
Grade data sheets (chemistry, mechanicals, equivalents) are on our reference site: DX51D · S250GD · DX52D
Frequently asked questions
What colour is RAL 6009?
Fir green — a very dark blue-shaded green (LRV ≈ 5 %) that reads as black in shade and deep pine green in sun; the standard fence, gate and forest-roof green on PPGI.
What is the difference between RAL 6009 and RAL 6005?
6005 moss green is lighter, warmer and the usual agricultural roof green; 6009 is darker and bluer and is chosen for fences and buildings that must disappear against trees.
Does RAL 6009 fade?
The pigments (chromium oxide, phthalocyanine) do not fade; plain polyester chalks slightly after 8–10 years on a hot south face. Matt-textured PE, SMP or PVDF keep it dark green longer.
Is RAL 6009 available in matt?
Yes — matt-textured PE to order from 10 t; gloss PE 0.40–0.50 mm is the stock finish.
Do you make fence panels in RAL 6009?
Yes — trapezoidal fence sheet cut to height, gate skins, post caps and rails folded from the same coil, and screws with 6009 heads, all from one batch.
What is the price of RAL 6009 PPGI?
About 30 USD/t over RAL 9002 in PE; see the indicative FOB Istanbul bands above. Matt, SMP and PVDF are quoted per project from 10 t.
